MEYLE HD range 110mm reinforced transmission selector, located between gearbox output and driveshaft , for BMW 1 Series E81 3-door Saloon, E87, E87LCi 5-door Saloon, E82 Coupé and E88 Cabriolet with manual gearbox only:
E81 3-door sedan :
- 116i 115hp from 04/2007 to 12/2011 (engine code N45B16)
- 116i 122hp from 03/2007 to 11/2011 (engine code N43B16)
- 116i 2.0L 122hp from 11/2008 to 11/2011 (engine code N43B20)
- 118i 2.0L 129hp from 09/2006 to 12/2011 (engine code N46B20)
- 118i 2.0L 143hp from 02/2006 to 12/2011 (engine code N43B20)
- 120i 150hp from 09/2006 to 10/2011 (engine code N46B20)
- 120i 170hp from 09/2006 to 12/2011 (engine code N43B20)
E87 5-door sedan :
- 116i 115hp from 03/2003 to 02/2007 (engine code N45B16)
- 118i 2.0L 129hp from 07/2004 to 02/2007 (engine code N46B20)
- 120i 150hp from 03/2003 to 02/2007 (engine code N46B20)
E87LCI 5-door sedan :
- 116i 115hp from 02/2006 to 06/2011 (engine code N45B16)
- 116i 122hp from 03/2007 to 06/2011 (engine code N43B16)
- 116i 2.0L 122hp from 10/2008 to 06/2011 (engine code N43B20)
- 118i 2.0L 129hp from 10/2006 to 06/2011 (engine code N46B20)
- 118i 2.0L 143hp from 02/2006 to 06/2011 (engine code N43B20)
- 120i 150hp from 09/2006 to 06/2011 (engine code N46B20)
- 120i 170hp from 02/2006 to 06/2011 (engine code N43B20)
E82 Coupé :
- 120i 150hp from 06/2009 to 10/2013 (engine code N46B20)
- 120i 170hp from 06/2009 to 09/2013 (engine code N43B20)
E88 Cabriolet :
- 118i 2.0L 129hp from 03/2008 to 09/2013 (engine code N46B20)
- 118i 2.0L 143hp from 09/2007 to 10/2013 (engine code N43B20)
- 120i 150hp from 11/2006 to 10/2013 (engine code N46B20)
- 120i 170hp from 11/2006 to 10/2013 (engine code N43B20)
ATTENTION: Not suitable for models with automatic gearbox!
Screws and bolts included (6 M10X50-10.9 screws and 6 M10 self-locking hex nuts).
Dimensions:
- Mounting centres: 78mm (6 holes)
- Outside diameter: 110mm
- Inside diameter: 40mm
- Thickness: 28mm
This bearing offers optimized quality compared to the original, with design flaws corrected and greater strength for improved durability and roadholding.
