Cylinder head

Technical data CB Perf "044" cylinder heads:
- optimized double intake Top Quality!
- reinforced combustion chambers: 55 cc
- improved cooling (keyed fins)
- intake valves: 40 mm stainless steel
- exhaust valves: 35.5 mm stainless steel
- springs: extra-hard double springs
- valve cotters : Chromoly
- valve guides: bronze-silicone
- spark plugs: 12 mm long (VC32115 not supplied)
- cylinder head bore: 94 mm
for displacement kits :
- 85.5 mm: 1600cc
- 87 mm: 1641cc (thin liners)
- 88 mm: 1679cc (thin liners)
Non-approved for road use, for private circuit use only

Technical data EMPI GTV-2 racing :
- dual intake type 1
- intake valves: stainless steel 40 mm
- exhaust valves: 35.5 mm stainless steel
- springs: single
- valve cotters : Chromoly
- chamber volume 55 cc
- spark plugs: 12 mm long (VC32115 not supplied)
- cylinder head bore: 94 mm
for displacement kits :
- 85.5 mm: 1600cc
- 87 mm: 1641cc (thin liners)
- 88 mm: 1679cc (thin liners)
- Inlet/exhaust ports 20% larger than stock cylinder heads.

Non-approved for road use, for private circuit use only.

EMPI GTV2 performance cylinder head, equivalent to CF Perf 044 Magnum.Ready to assemble on your engine, with 40 and 35.5 mm stainless steel valves and double springs for higher revs, this is an excellent performance part that can be used perfectly on a Daily.Sold individually, you'll need to order 2 to fit your vehicle.Suitable for 94mm Big Bore (thick liners)
Manufactured 100% by EMPI, each cylinder head is inspected and tested, and the cooling fins are increased in number to guarantee better cooling when the engine is being prepared. Spark plug and valve holes are reworked to increase strength by adding material, as are the inlet and outlet walls.
The spark plugs to be used must be 12mm diameter NGK type and not the original 14mm.
Non-approved for road use, for private circuit use only.

New cylinder head for Type 4 engine 1700 66hp (CA, CB), 62hp (CE)
with holes for EGR gas purging system.
(can be obstructed for mounting without).
Valves, admission : 39.3 mm exhaust: 33 mm

For CombiBay Window, 08/1971 ->12/1973

New cylinder head for Type 4 engine 1800 (AP) 68hp
with holes for EGR gas purging system.
(can be obstructed for mounting without).
Valves, admission : 39.3mm exhaust: 33 mm

For Combi Bay Window, 08/1973 ->07/1975

EMPI GTV2 performance cylinder head, equivalent to CF Perf 044 Magnum.Ready to assemble on your engine, with 40 and 35.5 mm stainless steel valves and single springs, this is an excellent performance part that can be used perfectly on a Daily.Sold individually, you need to order 2 to fit them to your vehicle.Suitable for displacement kits:- 90.5 mm : 1776 cc- 92 mm: 1835 cc (thin liners)
Manufactured 100% by EMPI, each cylinder head is inspected and tested, and the cooling fins are increased in number to guarantee better cooling when the engine is being prepared. Spark plug and valve holes are reworked to increase strength by adding material, as are the inlet and outlet walls.
Spark plugs to be used must be 12mm diameter NGK type and not the original 14mm.
Not approved for road use, reserved for private use on circuits.

Type 044performance cylinder head.Ready to assemble on your engine with its 40 and 35.5 mm valves and single springs, this is an excellent performance part that can be perfectly used on a Daily.Sold individually, you'll need to order 2 to fit them to your vehicle.Suitable for displacement kits:- 85.5 mm: 1600cc- 87 mm: 1641cc (thin liners)- 88 mm: 1679cc (thin liners)
Non-approved for road use, for private circuit use only

New and complete 1600cc double intake cylinder head
Intake valves: 35.5 mm
Exhaust valves: 32 mm
Spark plug type: long body not provided
Offers greater resistance thanks to the excess material around the spark plug shafts. Perfect for achieving greater reliability in a heavy vehicle such as a Camper. To be used with unleaded petrol.

For Type 1 engines: 1600 AD or AS.

Cylinder head with valve guides camshaft bearing caps
(push rods, valves, camshaft and cylinder head cover not included)

Cylinder head 1600cc double intake aluminium 040 original type.Make: EMPIFluid intake and exhaust pipesStainless steel intake valves: 35.5 mm Stainless-steel exhaust valves: 32 mmValve guides : BronzeValve springs : SingleSpark plug type: 14 mm short base (VC32100Q) not supplied. Compatible with unleaded gasoline.
Suitable for Type 1 engines: 1600cc AD / AS / AG / AL / AM.

Technical data CB Perf "044" cylinder heads :
- optimized double intake Top Quality!
- reinforced combustion chambers: 55 cc
- improved cooling (keyed fins)
- intake valves: 40 mm stainless steel
- exhaust valves: 35.5 mm stainless steel
- springs: extra-hard double springs
- valve cotters: chromoly
- valve guides: bronze-silicone
- spark plugs: 12 mm long (VC32115 not supplied)
- cylinder head bore: 101 mm
for displacement kits :
- 94 mm: 1915cc - 2054cc - 2165cc - 2276cc - 2387cc

Non-approved for road use, for private circuit use only

Complete new cylinder head for Type 4 1.7L engine
Valves, intake: 39 mm exhaust: 33 mm

Not suitable for fuel-injected versions.
Model with exhaust outlet under step-shaped oval cylinder head.

For VW Combi Bay Window from 08/1967 to 07/1979 carbureted version

1 original-style 040 aluminum 1600cc double-entry cylinder head.
Brand: AutoLinea by Empi
Fluid intake and exhaust ports
Stainless steel intake valves: 35.5 mm
Stainless-steel exhaust valves: 32 mm
Valve guides : Bronze
Valve springs : Single
Spark plug type: 14 mm short base (VC32100Q) not supplied.
Compatible with unleaded gasoline.

For Type 1 engines: 1600cc AD / AS / AG / AL / AM.
